MidiPlus : Studio 4 MidiPlus

Professional sound card, two high quality mic preamps, 4-in/4-out, 24-bit/192kHz with 2 Mic/Line/Instrument Inputs, USB Bus Power - Mac/PC
หมายเลขสินค้า : Studio4

ราคา 6,990.00 บาท

เลือกจำนวน :

เลือกสี : สีเงิน

  • สีเงิน

แชร์ไปยัง :

Professional sound card, two high quality mic preamps, 4-in/4-out, 24-bit/192kHz with 2 Mic/Line/Instrument Inputs, USB Bus Power - Mac/PC

ออดิโอ อินเตอร์เฟส ขนาด 4 in/4 out แบบ Combo Input XLR/Instrument มาพร้อมช่อง Midi in/out ความละเอียด 24 Bit/192 kHz มาพร้อมแผงไฟ LED บอกสถานะของ Gain Input สัญญาณเข้าอย่างละเอียด สามารถใช้ได้ทั้ง Mac และ Windows แถมฟรีโปรแกรมบันทึกเสียง Bitwig 8-Track


It's an audio interface which has 4 and 4 out, with high quaity microphone amp and 24bit/192kHz high accuracy sampling, 48V phantom power, support Micro US8 USB power supply, and the transmission rate of USB2.0 interface (support 3.0) is satisfying. STUDIO 4 also has modern look, powerful functions, zero delay monitor, volume indicator, subtle and solid casing, to perfectly compatible with Mac OS and Windows 7 above systems. This manual can help to know the functions quickly operations of STUDIO 4, please keep it for checking.

  • 24bit/192kHz high precision audio interface with 4 in and 4 out
  • Two XLR/TRS hybrid input interfaces, independent gain, with high resistance pattern can connect with Guitar, button with 48V phantom power
  • Zero delay four balance line out, two balance line in, monitor balance output
  • Back light for input gain knob, for checking input signal gain range
  • Adjust monitor headphone and volume of monitoring speaker separately
  • Four groups LED level indicator, display 4 input level in real time
  • High speed USB 2.0 port, Micro USB 5V extra power supply port
  • Mono/ Stereo switch
  • Input/output monitor switch
  • MIDI input and output interface

  • Product name : Studio 4
  • Sampling rate : 24Bit/192KHz
  • Input interface : Two 6.35mm balanced Input MIDI Input
  • Output Interface : Four 6.35mm balanced output headphone output Interface monitor output MIDI output
  • External device interface : An M-REMOTE Interface
  • USB hub : A USB2.0 hub
  • Phantom power : 48V
  • Button : Two LINE/INST switch one 48V phantom power swiltch one STEREO/MONO switch
  • Knob : Two input gain knobs one headphone volume adjustment knob one monitor volume adjustment knob
  • LED Indicator : LED level indicator, USB connection prompt light 48v phantom power indicator monitor channel Indicator
  • Power supply : Micro USB 5V power supply
  • Dimensiorn : 191 120*48(mm)
  • Welght : 690g
  • Accessorles : USB cable Micro USB cable information card Audio connector Manual
